A cluster of antennas send power wirelessly to a receiver antenna. System level simulations of wireless power and communication are hard because of complex interactions between electromagnetic and circuit phenomena. Furthermore, software platforms that simulate circuits are distinct from those that simulate electromagnetics.
To produce simulations such as this one, we at Noumenon have developed a technique of mathematically merging these two platforms to achieve speed and accuracy of a multi-domain simulation.
